Corrosion Resistance 316H Stainless Steel Plates UNS S31609 0.04-0.09% Carbon SS Sheets

Brand Name : TISCO

Model Number : 316H

Certification : ISO

Place of Origin : China

MOQ : 500 kgs

Price : 1300 - 1480 USD/Ton

Payment Terms : T/T, Western Union, L/C

Supply Ability : 10 Ton per week

Delivery Time : 5 - 12 days based on the quantity

Packaging Details : standard packing for export

Products : Stainless Steel Sheet

Grade : 316H

Standard : ASTM EN JIS GB

Size : 1219*2438mm

Thickness : 0.5 - 3.0mm

Type : cold rolled

Service : cutting, surface treatment

application : auto exhaust pipe

Packing : wooden pallets

Contact Now

Corrosion Resistance 316H Stainless Steel Plates UNS S31609 0.04-0.09% Carbon SS Sheets

Products Specification

Product Name
316H Stainless Steel Sheets
Material Type
Ferrite stainless steel, magnetic; Austenitic stainless steel, Non-magnetic.


Grade
300series:301,302,303,304,304L,309,309s,310,310S,316,316L,316Ti,317L,321,347
200series:201,202,202cu,204
400series:409,409L,410,420,430,431,439,440,441,444
Others:2205,2507,2906,330,660,630,631,17-4ph,17-7ph, S318039 904L,etc
Duplex stainless steel:S22053,S25073,S22253,S31803,S32205,S32304
Special Stainless Steel:904L,347/347H,317/317L,316Ti,254Mo
Technology
Cold Rolled /Hot Rolled
Length
2000/2438/2500/3000/3048 mm
Width
1000/1219/1250/1500 mm
Thickness
0.4-3mm(cold Rolled), 3-200mm(hot Rolled)
Surface
BA, 2B, NO.1,2D, 4K, 6K, 8K, NO.4, HL, SB, Embossed,perforated etc.
Leveling: improve flatness, esp. for items with high flatness request.
Skin-Pass: improve flatness, higher brightness
Other Choices
Cutting:Laser cutting, help the customer to cut the required size
Protection
1. Inter paper available
2. PVC protecting film available
Price Item
FOB,CIF,DDU,FCA,EXW ,.etc
Quality Assurance
1.Provide MTC (Mill Test).
2.Accept the inspection by the third party agent

Chemical Composition of Type 316H Stainless Steel

The chemical composition of Type 316H Stainless Steel is provided in the table below.

UNS NO Grade C Si Mn P S Cr Mo Ni N
S31609 316H 0.04/0.10 0.75 2.00 0.045 0.030 16.00/18.00 2.00/3.00 10.00/14.00 -

Mechanical Properties of Type 316H Stainless Steel

The mechanical properties of Type 316H Stainless Steel are provided in the table below.

UNS No Grade Proof Stress
0.2% (MPa)		 Tensile Strength
(MPa)		 Elongation
A5(%)		 Hardness Max
HB HRB
S31609 316H 205 515 40 217 95

316H Stainless Steel Sheets and Plates in Stock

Cold Rolled 316H Stainlesss Steel Sheets
0.3*1219*2438mm 0.4*1219*2438mm 0.5*1219*2438mm 0.6*1219*2438mm
0.8*1219*2438mm 1.0*1219*2438mm 1.2*1219*2438mm 1.5*1219*2438mm
2.0*1219*2438mm 2.5*1219*2438mm 3.0*1219*2438mm
Hot Rolled 316H Stainless Steel Plates
3.0*1500*6000mm 4.0*1500*6000mm 5.0*1500*6000mm 6.0*1500*6000mm
8.0*1500*6000mm 10.0*1500*6000mm 12.0*1500*6000mm 14.0*1500*6000mm
16.0*1500*6000mm 18.0*1500*6000mm 20.0*1500*6000mm 25.0*1500*6000mm
30.0*1500*6000mm 35.0*1500*6000mm 40.0*1500*6000mm 45.0*1500*6000mm

Advantage of our company

  • 1,Large scale of metal products in our store and more than 2000+ tons in stocks for quick shipment
  • 2,We have got the certifications of CE,ISO,SGS officially.
  • 3,We are the verified golden supplier on Alibaba.com and our clients come from 10+ countries.
  • Trade assurance orders on Alibaba.com will guarantee the safety of deals for both of us.
  • 4,The raw material is bought from Chinese famous steel factories. All our products are inspected strictly
  • MTC reports is provided with the shippment.
  • 5,The third party inspection is acceptable before delivery.
  • 6,24-hour online service will supply efficient after-service quickly.

Corrosion Resistance 316H Stainless Steel Plates UNS S31609 0.04-0.09% Carbon SS SheetsCorrosion Resistance 316H Stainless Steel Plates UNS S31609 0.04-0.09% Carbon SS SheetsCorrosion Resistance 316H Stainless Steel Plates UNS S31609 0.04-0.09% Carbon SS SheetsCorrosion Resistance 316H Stainless Steel Plates UNS S31609 0.04-0.09% Carbon SS Sheets
